Lake Royale

The Division of Water Resources (DWR) provides the data contained within this Local Water Supply Plan (LWSP) as a courtesy and service to our customers. DWR staff does not field verify data. Neither DWR, nor any other party involved in the preparation of this LWSP attests that the data is completely free of errors and omissions. Furthermore, data users are cautioned that LWSPs labeled PROVISIONAL have yet to be reviewed by DWR staff. Subsequent review may result in significant revision. Questions regarding the accuracy or limitations of usage of this data should be directed to the water system and/or DWR.

1. System Information

Contact Information

Complete

Water System Name: Lake Royale   PWSID: 02-35-108
Mailing Address:1630 Des Peres Rd., Suite 140
Des Peres, MO 63131		Ownership:Business

Contact Person:Joseph JohnsonTitle:Compliance Coordinator
Phone:314-380-9498Cell/Mobile:--

Secondary Contact:Arthur Faiello Phone:314-464-3618
Mailing Address:1630 Des Peres Rd.
Des Peres, MO 63131		Cell/Mobile:--
Distribution System
Line Type Size Range (Inches) Estimated % of lines
Polyvinyl Chloride 2-10 100.00 %
What are the estimated total miles of distribution system lines?   70 Miles
How many feet of distribution lines were replaced during 2024?   750 Feet
How many feet of new water mains were added during 2024?   0 Feet
How many meters were replaced in 2024?   5
How old are the oldest meters in this system?   24 Year(s)
How many meters for outdoor water use, such as irrigation, are not billed for sewer services?   0
What is this system's finished water storage capacity?   0.2000 Million Gallons
Has water pressure been inadequate in any part of the system since last update? Line breaks that were repaired quickly should not be included.   No
Programs
Does this system have a program to work or flush hydrants?   Yes, As Needed
Does this system have a valve exercise program?   Yes, Annually
Does this system have a cross-connection program?   Yes
Does this system have a program to replace meters?   No
Does this system have a plumbing retrofit program?   No
Does this system have an active water conservation public education program?   No
Does this system have a leak detection program?   No
Water Conservation
What type of rate structure is used?   Increasing Block, Other
How much reclaimed water does this system use?   0.0000 MGD   For how many connections?   0
Does this system have an interconnection with another system capable of providing water in an emergency?   Yes

2. Water Use Information

Service Area
Sub-Basin(s)% of Service Population
Tar River (15-1)100 %
County(s)% of Service Population
Franklin90 %
Nash10 %
What was the year-round population served in 2024?   5,675
Has this system acquired another system since last report?   No
Water Use by Type
Type of Use Metered
Connections		 Metered
Average Use (MGD)		 Non-Metered
Connections		 Non-Metered
Estimated Use (MGD)
Residential 2,286 0.2000 0 0.0000
Commercial 15 0.0019 0 0.0000
Industrial 0 0.0000 0 0.0000
Institutional 0 0.0000 0 0.0000

How much water was used for system processes (backwash, line cleaning, flushing, etc.)?   0.0360 MGD

3. Water Supply Sources

Monthly Withdrawals & Purchases
Average Daily
Use (MGD)		 Max Day
Use (MGD)		 Average Daily
Use (MGD)		 Max Day
Use (MGD)		 Average Daily
Use (MGD)		 Max Day
Use (MGD)
Jan 0.2270 0.3190 May 0.2570 0.3800 Sep 0.2150 0.4790
Feb 0.2020 0.3010 Jun 0.3480 0.4950 Oct 0.2350 0.4290
Mar 0.2280 0.3700 Jul 0.3070 0.5360 Nov 0.2120 0.4370
Apr 0.2590 0.3860 Aug 0.2370 0.5860 Dec 0.2350 0.6050

Water Purchases From Other Systems
Seller PWSID Average
Daily Purchased
(MGD)		 Days
Used		 Contract Required to
comply with water
use restrictions?		 Pipe Size(s)
(Inches)		 Use
Type
MGD Expiration Recurring
Franklin Co. WSD 02-35-030 0.2470 365 0.3600 2039 Yes Yes 6 Regular

4. Wastewater Information

Monthly Discharges
Average Daily
Discharge (MGD)		 Average Daily
Discharge (MGD)		 Average Daily
Discharge (MGD)
Jan 0.0030 May 0.0040 Sep 0.0040
Feb 0.0030 Jun 0.0030 Oct 0.0030
Mar 0.0030 Jul 0.0040 Nov 0.0030
Apr 0.0030 Aug 0.0040 Dec 0.0030

How many sewer connections does this system have?   2
How many water service connections with septic systems does this system have?   2,208
Are there plans to build or expand wastewater treatment facilities in the next 10 years?   No
Wastewater Permits
Permit Number Type Permitted Capacity
(MGD)		 Design Capacity
(MGD)		 Average Annual
Daily Discharge
(MGD)		 Maximum Day Discharge
(MGD)		 Receiving Stream Receiving Basin
NC0042510 WWTP 0.0800 0.0800 0.0033 7200.0000 Cypress Creek Tar River (15-1)

5. Planning

Projections
  2024 2030 2040 2050 2060 2070
Year-Round Population 5,675 5,725 5,781 5,954 6,133 6,317
Seasonal Population 0 0 0 0 0 0

Residential 0.2000 0.2150 0.2200 0.2250 0.2270 0.2300
Commercial 0.0019 0.0019 0.0020 0.0021 0.0022 0.0023
Industrial 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000
Institutional 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000
System Process 0.0360 0.0100 0.0100 0.0100 0.0100 0.0100
Unaccounted-for 0.0084 0.0250 0.0250 0.0250 0.0300 0.0300
Demand v/s Percent of Supply
  2024 2030 2040 2050 2060 2070
Surface Water Supply 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000
Ground Water Supply 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000
Purchases 0.3600 0.3600 0.3600 0.3600 0.3600 0.3600
Future Supplies 0.0000 0.0000 0.0000 0.0000 0.0000
Total Available Supply (MGD) 0.3600 0.3600 0.3600 0.3600 0.3600 0.3600
Service Area Demand 0.2463 0.2519 0.2570 0.2621 0.2692 0.2723
Sales 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000
Future Sales 0.0000 0.0000 0.0000 0.0000 0.0000
Total Demand (MGD) 0.2463 0.2519 0.2570 0.2621 0.2692 0.2723
Demand as Percent of Supply 68% 70% 71% 73% 75% 76%

The purpose of the above chart is to show a general indication of how the long-term per capita water demand changes over time. The per capita water demand may actually be different than indicated due to seasonal populations and the accuracy of data submitted. Water systems that have calculated long-term per capita water demand based on a methodology that produces different results may submit their information in the notes field.

Your long-term water demand is 35 gallons per capita per day. What demand management practices do you plan to implement to reduce the per capita water demand (i.e. conduct regular water audits, implement a plumbing retrofit program, employ practices such as rainwater harvesting or reclaimed water)? If these practices are covered elsewhere in your plan, indicate where the practices are discussed here.    No changes

Are there other demand management practices you will implement to reduce your future supply needs?   No changes

What supplies other than the ones listed in future supplies are being considered to meet your future supply needs?   No changes

How does the water system intend to implement the demand management and supply planning components above?   No changes

Additional Information

Has this system participated in regional water supply or water use planning?  No

What major water supply reports or studies were used for planning?

Please describe any other needs or issues regarding your water supply sources, any water system deficiencies or needed improvements (storage, treatment, etc.) or your ability to meet present and future water needs. Include both quantity and quality considerations, as well as financial, technical, managerial, permitting, and compliance issues:
