Bath

The Division of Water Resources (DWR) provides the data contained within this Local Water Supply Plan (LWSP) as a courtesy and service to our customers. DWR staff does not field verify data. Neither DWR, nor any other party involved in the preparation of this LWSP attests that the data is completely free of errors and omissions. Furthermore, data users are cautioned that LWSPs labeled PROVISIONAL have yet to be reviewed by DWR staff. Subsequent review may result in significant revision. Questions regarding the accuracy or limitations of usage of this data should be directed to the water system and/or DWR.

1. System Information

Contact Information

Complete

Water System Name: Bath   PWSID: 04-07-030
Mailing Address:P.O. Box 6A
Bath, NC 27889		Ownership:Municipality

Contact Person:Sonny GrantTitle:Utilities Manager
Phone:252-923-0917Cell/Mobile:--

Secondary Contact:Mike Houston Phone:919-812-6088
Mailing Address:
, NC 		Cell/Mobile:--
Distribution System
Line Type Size Range (Inches) Estimated % of lines
Polyvinyl Chloride 2-6 100.00 %
What are the estimated total miles of distribution system lines?   12 Miles
How many feet of distribution lines were replaced during 2025?   0 Feet
How many feet of new water mains were added during 2025?   0 Feet
How many meters were replaced in 2025?   3
How old are the oldest meters in this system?   44 Year(s)
How many meters for outdoor water use, such as irrigation, are not billed for sewer services?   0
What is this system's finished water storage capacity?   0.0100 Million Gallons
Has water pressure been inadequate in any part of the system since last update? Line breaks that were repaired quickly should not be included.   No
Programs
Does this system have a program to work or flush hydrants?   Yes, Monthly
Does this system have a valve exercise program?   Yes, Monthly
Does this system have a cross-connection program?   Yes
Does this system have a program to replace meters?   No
Does this system have a plumbing retrofit program?   No
Does this system have an active water conservation public education program?   No
Does this system have a leak detection program?   Yes

As employees ride throughout the system, they look for leaks and utilize NCRWA on an as needed.

Water Conservation
What type of rate structure is used?   Increasing Block
How much reclaimed water does this system use?   0.0000 MGD   For how many connections?   0
Does this system have an interconnection with another system capable of providing water in an emergency?   Yes

2. Water Use Information

Service Area
Sub-Basin(s)% of Service Population
Pamlico River & Sound (15-3)100 %
County(s)% of Service Population
Beaufort100 %
What was the year-round population served in 2025?   290
Has this system acquired another system since last report?   No
Water Use by Type
Type of Use Metered
Connections		 Metered
Average Use (MGD)		 Non-Metered
Connections		 Non-Metered
Estimated Use (MGD)
Residential 185 0.0153 0 0.0000
Commercial 14 0.0018 0 0.0000
Industrial 0 0.0000 0 0.0000
Institutional 12 0.0031 0 0.0000

How much water was used for system processes (backwash, line cleaning, flushing, etc.)?   0.0001 MGD

3. Water Supply Sources

Monthly Withdrawals & Purchases
Average Daily
Use (MGD)		 Max Day
Use (MGD)		 Average Daily
Use (MGD)		 Max Day
Use (MGD)		 Average Daily
Use (MGD)		 Max Day
Use (MGD)
Jan 0.0197 May 0.0234 Sep 0.0253
Feb 0.0237 Jun 0.0253 Oct 0.0215
Mar 0.0184 Jul 0.0227 Nov 0.0221
Apr 0.0246 Aug 0.0231 Dec 0.0216

Ground Water Sources
Name or Number Average Daily Withdrawal (MGD) Max Day Withdrawal (MGD) 12-Hour Supply
(MGD)		 CUA Reduction Year Offline Use Type
MGD Days Used
1 0.0000 0 0.1660 Regular
2 0.0000 0 0.1440 2007 Regular
Ground Water Sources (continued)
Name or Number Well Depth (Feet) Casing Depth
(Feet)		 Screen Depth (Feet) Well Diameter (Inches) Pump Intake Depth (Feet) Metered?
Top Bottom
1 174 0 0 0 6 0 Yes
2 123 0 0 0 6 0 Yes
Are ground water levels monitored?   No,
Does this system have a wellhead protection program?   No
Water Purchases From Other Systems
Seller PWSID Average
Daily Purchased
(MGD)		 Days
Used		 Contract Required to
comply with water
use restrictions?		 Pipe Size(s)
(Inches)		 Use
Type
MGD Expiration Recurring
Beaufort Co (Northside) 04-07-035 0.0226 365 0.0000 2018 Yes No 6 Regular
Water Treatment Plants
Plant Name Permitted Capacity
(MGD)		 Is Raw Water Metered? Is Finished Water Ouput Metered? Source
Bath WTP 0.0500 No Yes 1 deep well & purchased water as needed
Did average daily water production exceed 80% of approved plant capacity for five consecutive days during 2025?  No
     If yes, was any water conservation implemented?  No
Did average daily water production exceed 90% of approved plant capacity for five consecutive days during 2025?  No
     If yes, was any water conservation implemented?  No
Are peak day demands expected to exceed the water treatment plant capacity in the next 10 years?  No

4. Wastewater Information

Monthly Discharges
Average Daily
Discharge (MGD)		 Average Daily
Discharge (MGD)		 Average Daily
Discharge (MGD)
Jan 0.0151 May 0.0191 Sep 0.0188
Feb 0.0164 Jun 0.0174 Oct 0.0167
Mar 0.0172 Jul 0.0178 Nov 0.0183
Apr 0.0175 Aug 0.0188 Dec 0.0167

How many sewer connections does this system have?   191
How many water service connections with septic systems does this system have?   14
Are there plans to build or expand wastewater treatment facilities in the next 10 years?   No
Wastewater Permits
Permit Number Type Permitted Capacity
(MGD)		 Design Capacity
(MGD)		 Average Annual
Daily Discharge
(MGD)		 Maximum Day Discharge
(MGD)		 Receiving Stream Receiving Basin
WQ0002520 WWTP 0.0220 0.0400 0.0175 Spray Irrigation Pamlico River & Sound (15-3)

5. Planning

Projections
  2025 2030 2040 2050 2060 2070
Year-Round Population 290 290 290 290 290 290
Seasonal Population 0 0 0 0 0 0

Residential 0.0153 0.0153 0.0153 0.0153 0.0153 0.0153
Commercial 0.0018 0.0018 0.0018 0.0018 0.0018 0.0018
Industrial 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000
Institutional 0.0031 0.0031 0.0031 0.0031 0.0031 0.0031
System Process 0.0001 0.0001 0.0001 0.0001 0.0001 0.0001
Unaccounted-for 0.0023 0.0023 0.0023 0.0023 0.0023 0.0023

No expected growth up or down is expected in the coming years for the Town of Bath.

Demand v/s Percent of Supply
  2025 2030 2040 2050 2060 2070
Surface Water Supply 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000
Ground Water Supply 0.3100 0.1660 0.1660 0.1660 0.1660 0.1660
Purchases 0.0226 0.0226 0.0226 0.0226 0.0226 0.0226
Future Supplies 0.0000 0.0000 0.0000 0.0000 0.0000
Total Available Supply (MGD) 0.3326 0.1886 0.1886 0.1886 0.1886 0.1886
Service Area Demand 0.0226 0.0226 0.0226 0.0226 0.0226 0.0226
Sales 0.0000 0.0000 0.0000 0.0000 0.0000 0.0000
Future Sales 0.0000 0.0000 0.0000 0.0000 0.0000
Total Demand (MGD) 0.0226 0.0226 0.0226 0.0226 0.0226 0.0226
Demand as Percent of Supply 7% 12% 12% 12% 12% 12%

The purpose of the above chart is to show a general indication of how the long-term per capita water demand changes over time. The per capita water demand may actually be different than indicated due to seasonal populations and the accuracy of data submitted. Water systems that have calculated long-term per capita water demand based on a methodology that produces different results may submit their information in the notes field.

Your long-term water demand is 53 gallons per capita per day. What demand management practices do you plan to implement to reduce the per capita water demand (i.e. conduct regular water audits, implement a plumbing retrofit program, employ practices such as rainwater harvesting or reclaimed water)? If these practices are covered elsewhere in your plan, indicate where the practices are discussed here.    No Changes

Are there other demand management practices you will implement to reduce your future supply needs?   No Changes

What supplies other than the ones listed in future supplies are being considered to meet your future supply needs?   No Changes

How does the water system intend to implement the demand management and supply planning components above?   No Changes

Additional Information

Has this system participated in regional water supply or water use planning?  No

What major water supply reports or studies were used for planning?  N/A

Please describe any other needs or issues regarding your water supply sources, any water system deficiencies or needed improvements (storage, treatment, etc.) or your ability to meet present and future water needs. Include both quantity and quality considerations, as well as financial, technical, managerial, permitting, and compliance issues:   N/A
